Right-Angle SMA Female Through-Hole PCB Mount Connector

Description

Features:

1. Through Hole, Pcb Mount, Jack/female, Angled/90°, 50Ω;
2. Excellent electrical performance up to 18GHz with low reflection;
3. Thread type coupling mechanism ensure small loss and high security in a compact design;
4. High Quality with 30 days 100% Money back;
5. From the OEM Original Factory, same quality with much better price.

Specifications:

Electrical Characteristics

1. Impedance：50 ohm
2. Frequency Range: 0~6 GHz
3. VSWR: Straight type ≦ 1.3max / R/A type ≦ 1.5max
4. Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405
   750 V rms min. for RG316, RG402
   500v rms min. for RG178
5. Working Voltage: 500 V rms max. for RG142, RG405
   375 V rms max. for RG316, RG402
   170 V rms max. for RG178
6. Center Contact Resistance ≦ 6.0 mΩ  (Milliohms max.)
7. Outer Contact Resistance ≦ 2.0 mΩ  (Milliohms max.)
8. Insultation Resistance ≧ 5 x 10³ mΩ (Megohms min.)

Mechanical Characteristics

1. Coupling: 1/4-36 thread
2. Contact Retention: 15 in-lbs min.
3. Coupling nut torque: 30 in-lbs. min.
4. Durability(mating) ≧ 500 cycles (For Beryllium Copper Contact)

Environmental Characteristics

1. Environmental Characteristics: -65°C ~ +165°C
2. Vibration: MIL-STD-202 Meth.204
3. Corrosion resistance: MIL-STD-202 Meth. 101
