MJE340 NPN High-Voltage Power Transistor – General-Purpose Amplifier/Switch for Medium-Power Applications

Description

Features:-

• Part No: MJE340
• Brand: CDIL
• NPN, Silicon
• Max Collector Continuous Current: 500 mA
• Max Collector-Emitter Voltage: 300 V
• MJE340 NPN Bipolar Power Transistor

—

This device is useful for high-voltage general purpose applications, MJE340 is a TO-126 package NPN silicon BJT transistor designed for high voltage applications. The Maximum collector-emitter and collector-base voltage of the transistor are up to 300V which makes it ideal to use in a wide variety of high voltage applications. The device can be used with any general high voltage switching application for the max load of 0.5A or 500mA DC. Additionally, it can also be used for switching in low-power and battery-operated applications.

MJE340 is not only limited to use for the above-mentioned purposes however it can also be used for amplification purposes, also the 20W collector dissipation makes it ideal to use in many general-purpose audio amplification purposes.

Features:-

• High DC current gain

• Low collector−emitter saturation voltage

• High current−gain − bandwidth product

• Annular construction for low leakage
