FM Radio Receiver Module Based on AR1010 Chip

Description

A very small single chip FM receiver module found in many portable media players. Based on the AR1010 IC from Airoha, the FM receiver uses a simple command set over an I2C or SPI interface. Crystal and supporting components are all on board, all you need to attach is an antenna.

Features:

• World Channel, the frequency range from 76-108MHZ automatic digital tuning
• High sensitivity, high stability, low noise, low power consumption
• Radio modules, ultra-small size
• High sensitivity with integrated low-noise RF input amplifier
• Built in 32.768khz clock crystal

Specifications:

• 3.3V @ 11mA
• 76-108MHz supported
• 100mV audio output
• Stereo output
