CD4072 Dual 4-Input OR Gate – CMOS Logic IC, 14-Pin DIP

Description

Specifications:-

• Part number    CD4072B
• Technology Family    CD4000
• VCC (Min) (V)    3
• VCC (Max) (V)    18
• Channels (#)    2
• Inputs per channel    4
• Input type    Standard CMOS
• Output type    Push-Pull
• Features    Standard Speed (tpd > 50ns)
• IOL (Max) (mA)    6.8
• IOH (Max) (mA)    -6.8
• Data rate (Max) (Mbps)    8
• Rating    See Data Sheet
• Operating temperature range (C)    -55 to 125

CD4072 OR gates provide the system designer with direct implementation of the positive-logic OR function and supplement the existing family of CMOS gates.

The CD4072  types are supplied in 14-lead hermetic dual-in-line ceramic packages (F3A suffix), 14-lead dual-in-line plastic packages (E suffix), 14-lead small-outline packages (M, MT, M96, and NSR suffixes) and 14-lead thin shrink small-outline packages (PW and PWR suffixes).

Features:-

• Medium-Speed Operation – t_PLH, t_PHL = 60 ns (typ.) at V_DD = 10 V
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C
• Standardized, symmetrical output characteristics
• Noise margin (full package-temperature range):
  1 V at V_DD = 5 V
  2 V at V_DD = 10 V
  2.5 V at V_DD = 15 V
• 5-V, 10-V, and 15-V parametric ratings
• Meets all requirements of JEDEC Tentative Standard No. 13B, “Standard Specifications for Description of ’B’ Series CMOS Devices”
