CD4051BE 8-Channel Analog Multiplexer/Demultiplexer IC – DIP-16 Package

Description

Features:-

• Wide Range of Digital and Analog Signal Levels
  • Digital: 3 V to 20 V
  • Analog: ≤20 V_P-P
• Low ON Resistance,125 Ω (Typical) Over 15 V_P-P Signal Input Range for V_DD – V_EE = 18 V
• High OFF Resistance, Channel Leakage of ±100 pA (Typical) at V_DD – V_EE = 18 V
• Logic-Level Conversion for Digital Addressing Signals of 3 V to 20 V (V_DD – V_SS = 3 V to 20 V) to Switch Analog Signals to 20 V_P-P (V_DD – V_EE = 20 V) Matched Switch Characteristics, r_ON = 5 Ω (Typical) for V_DD – V_EE = 15 V Very Low Quiescent Power Dissipation Under All Digital-Control Input and Supply Conditions, 0.2 µW (Typical) at V_DD – V_SS = V_DD – V_EE = 10 V
• Binary Address Decoding on Chip
• 5 V, 10 V, and 15 V Parametric Ratings
• 100% Tested for Quiescent Current at 20 V
• Maximum Input Current of 1 µA at 18 V Over Full Package Temperature Range, 100 nA at 18 V and 25°C
• Break-Before-Make Switching Eliminates Channel Overlap

The CD4051 analog multiplexers and demuliplexers are digitally-controlled analog switches having low ON impedance and very low OFF leakage current. These multiplexer circuits dissipate extremely low quiescent power over the full V_DD – V_SS and V_DD – V_EE supply-voltage ranges, independent of the logic state of the control signals.
