Description
- Supply Voltage: 5V
- Pulse Duration(High): 20 ns
- Pulse Duration(Low): 47 ns
- Operating free-air temperature: -55 to 125°C
The 7473 offers individual J, K, clear, and clock inputs. These dual flip-flops are designed so that when the clock goes HIGH, the inputs are enabled and data will be accepted. The logic level of the J and K inputs may be allowed to change when the clock pulse is HIGH and the bistable will perform according to the truth table as long as minimum set-up times are observed. Input data is transferred to the outputs on the negative-going edge of the clock pulse.
