5V 10A RF Wireless Remote-Controlled Latching Relay Module

Description

• 1 Channel Wireless Relay Switch Channel: 1CH
• Output Current: 10A
• Input Voltage: DC5V
• Working Voltage: DC5V
• Standby Current: ＜5MA RF
• Frequency: 433MHZ
• Receiver Sensitivity: >90dBm
• Dimension (approx.):3.5*3*1.6cm
• RF Working mode: Super heterodyne receiver Remote
• Control Distance: >100 meter(In open environment)
• Decoding Way: MCU Software decoding
• Can store the number of remote control:
• 50 Support remote control type:
• Fixed code, learning code Wiring Method: Fixed wiring terminal
• Output: Normally open, Common, Normally closed Multiple
• working modes: (Jog/Non-Latched ,inter-lock/Latched ,self-lock /Self-Latched
