TowerPro MG958 Digital Servo Motor – High-Torque Metal Gear, 180° Rotation

Description

Specification:

• Weight: 65g
• Dimensions: 40.2 x 20.1 x 36.8mm
• Operating Voltage: 4.8v-6.6v
• Stall Torque (4.8v): 18.0kg.cm
• Stall Torque (6.6v): 20.0kg.cm
• Servo case: Alloy case in the middle
• Gear Type: Metal gear
• Bearing: Double ball bearing
• Temperature range: 0- 55deg
• Operating Temperature Range: 0 ~ +55 Degree C
• Operating Speed (4.8v): 0.18sec/60 degree
• Operating Speed (6.0v): 0.15sec/60 degree
• Servo wire length: 32cm
• Current draw at idle 10MA
• No load operating current draw 170MA
• Stall current draw 1600MA
• Servo Plug: JR (Fits JR and Futaba)
• Servo arms &screws included and fit with Futaba servo arm
• CE &RoHS approved

Wire Description

• Red – Positive
• Brown – Negative
• Orange – Signal
