TOF10120 Time-of-Flight Laser Distance Sensor Module – UART/I²C Interface, 3–5V Supply, 10–180 cm Range

Description

TOF10120 range sensor provides accurate and repeatable long range distance measurement for high-speed autofocus (AF). The innovative time-offlight technology allows performance independent of object reflectance. TOF10120’s time-of-flight sensing technology is realized by Sharp’s original SPAD (Single Photon Avalanche Diodes ) using low-cost standard CMOS process. It enables accurate ranging result, higher immunity to ambient light and better robustness to cover-glass optical cross-talk by special optical package design.Specifications::

• Ranging Range  100 – 1800mm
• VCC: 3 – 5V DC
• ICC_VDD: 35mA
• Topr  –  20 + 70 °C
• Tstg   –  40 + 85 °C
• Communication protocol
• Bits per Second:9600
• Data Bits : 8
• Parity : None
• Stop bits : 1
• Flow Control : None
• Small ceramic package(20×13.2×2.0mm)

Pinouts:

• GND – Black
• VCC – Red
• RXD – Yellow
• TXD – White
• SDA – Blue
• SCL – Purple

Package Included:1 x TOF10120 Laser Range Sensor Module 10-180cm Distance Sensor

Note: Product Images are shown for illustrative purposes only and may differ from the actual product
