ST MJE3055T NPN Power Transistor – 60V, 10A, TO-220 Package

Description

The MJE3055T is a silicon epitaxial-base NPN transistor in Jedec T0-220 package. It is for power switching circuits intended for general-purpose amplifiers. The complementary PNP type is MJE2955T.

Features:

• DC Current Gain Specified to 10 Amperes
• High Current Gain — Bandwidth Product —fT = 2.0 MHz (Min) @ IC = 500 mAdc

Specifications :

• Brand: STMicroelectronics
  Transistor Type: NPN
• Maximum DC Collector Current: 10 A
• Maximum Collector Emitter Voltage: 60 V
• Package Type: TO-220
• Mounting Type: Through Hole
• Maximum Power Dissipation: 75 W
• Minimum DC Current Gain: 20
• Transistor Configuration: Single
• Maximum Collector Base Voltage: 70 V
• Maximum Emitter Base Voltage: 5 V
• Maximum Operating Frequency: 2 MHz
• Pin Count: 3
• Number of Elements per Chip: 1
• Maximum Operating Temperature: +150 °C
