SLAMTEC RPLIDAR A1M8 – 360° Laser Distance Sensor, 6 m Range

Description

1. Distance Range (Radius): 0.15m to 6m, white objects (Diameter Range – 12m)
2. Angular Range: 0 ~ 360º
3. Distance Resolution: < 0.5mm
4. Angular Resolution: <= 1 º
5. Sample Duration: 0.5 ms
6. Sample Frequency: >=8000 Hz
7. Scan Rate: 1 ~ 10Hz, Typical 5.5Hz

Features:

1. Measuring distance: Up to 6 meters (Radius).
2. Measures distance data in more than 8000 times/s.
3. 360 Degree Omnidirectional Laser Range Scanning.
4. 8000 times sample rate, the highest in the current economical LIDAR industry.
5. OPTMAG Original Design, prolong the lifespan.
6. Configurable Scan Rate from 2-10Hz.
7. Ideal for Robot Navigation and Localization.
8. Plug and Play.
