Plug-and-Play Reed Switch Interface Module with Signal Conditioning

Description

1. Working voltage 3.3V-5
2. Output format: digital switching output (0 and 1)A
3. fixed bolt holes for easy installation

This module can be applied in Program-controlled switches, copiers, washing machines, refrigerators, cameras, Disinfection cabinet, door, window magnetic, electromagnetic relays, electronic weighing, level meter, gas meter, water meter, and so on.

Specifications and Features:

1. Clean, good waveform driving ability, more than 15mA.
2. Working voltage 3.3V-5
3. Output format: digital switching output (0 and 1)
4. A  fixed bolt holes for easy installation
5. PCB size: 3.2cm x 1.4cm
6. Digital output using a wide voltage LM393 comparator
