Description
The CD4017 is a 5-stage divide-by-10 Johnson counter with 10 decoded outputs and a carry out bit. The configuration of the CD4017 permits medium speed operation and assures a hazard free counting sequence. The 10/8 decoded outputs are normally in the logical “0” state and go to the logical “1” state only at their respective time slot. Each decoded output remains high for 1 full clock cycle. The carry-out signal completes a full cycle for every 10/8 clock input cycles and is used as a ripple carry signal to any succeeding stages.
Features:-
- Wide supply voltage range: 3.0V to 15V
- High noise immunity: 0.45 VDD (typ.)
- Low power Fan out of 2 driving 74L TTL compatibility: or 1 driving 74LS
- Medium speed operation: 5.0 MHz (typ.) with 10V VDD
- Low power: 10 µW (typ.)
- Fully static operation
Specifications:-
| Parameter | Specification |
| Input Voltage (VIN) | −0.5 VDC to VDD +0.5 VDC |
| Storage Temperature (TS) | −65°C to +150°C |
| DC Supply Voltage (VDD) | −0.5 VDC to +18 VDC |
| Power Dissipation (PD): Dual-In-Line | 700 mW |
| Lead Temperature (TL) | 260°C |
