Description
- 7447 BCD to 7-Segment Decoder/Driver IC DIP-16 Package
- Number of Input Lines: 4 Input
- Number of Output Lines: 7 Output
- Propagation Delay Time: 100 ns
- High Level Output Current: – 0.05 mA
- Logic Type: Decoders/Demultiplexers
- Low Level Output Current: 3.2 mA
- Maximum Clock Frequency: 35 MHz
- Number of Circuits: 1 Circuit
- Operating Supply Voltage: 5 V
- Package/Case: DIP-16
The 7447 is a BCD-to-Seven-segment Decoder/Driver features active-low outputs, designed for driving, common-anode LEDs or incandescent indicators directly. The IC for driving lamp buffers or common-cathode LEDs. All of the circuits except LS49 have full ripple-blanking input/output controls and a lamp test input. Display patterns for BCD input counts above 9 are unique symbols to authenticate input conditions.
