Description
- 8-Line to 1-Line Multiplexers
- Boolean Function Generators
- Parallel-to-Serial Converters
- Data Source Selectors
- Input Clamping Diodes Simplify System Design
These data selectors/multiplexers provide full binary decoding to select one-of-eight data sources. The strobe (G) input must be at a low logic level to enable the inputs. A high level at the strobe terminal forces the W output high and the Y output low. The SN54ALS151 is characterized for operation over the full military temperature range of -55°C to 125°C. The 74151 is characterized for operation from 0°C to 70°C.
