7408 Quad 2-Input AND Gate IC – Standard TTL Logic, DIP-14

Description

• 4 AND gates in a 14-Pin DIP Package
• Outputs Directly Interface to CMOS, NMOS and TTL
• Large Operating Voltage Range
• Wide Operating Conditions

Specifications:-

• Type: DIP Bipolar
• Voltage Rating: 2.0 to 6.0V
• Temperature Rating: 0 to 70Deg C
• Number of: 14 Pins
• Mounting: Through Hole

Switching specifications at 50 pF
Switching specifications guaranteed over full temperature and VCC range
Advanced oxide-isolated, ion-implanted Schottky TTL process
Functionally and pin for pin compatible with Schottky and low power Schottky TTL counterpart
Improved AC performance over Schottky and low power Schottky counterparts

7408 is a 14 PIN IC. The chip is available in different packages and is chosen depending on requirement
