5V 8-Channel 10A Relay Module – Optically Isolated for Noise Immunity

Description

The 8550 transistor drive, drivability.
A fixed bolt holes for easy installation.
It has a relay status indicator led Power LED(Green), 8 relay status indicator LED(Red)
Relay control interface by single-chip IO.
Low-level suction close, high-level release.
Easy to use, simple 3 line structure.

—

It is a 5V 8 Channel Relay Module. The relay normally open interface maximum load: AC 250V/10A, DC 30V/10A. It has a trigger current of 5mA, and module working voltage of DC 5V. Each channel of the module can be triggered by a jumper to set a high level or a low level. Fault-tolerant design, even if the control line is disconnected, the relay will not move. With status indicator: power (green), 6-channel relay status indicator (red). All module size interfaces can be directly connected through the terminal block, which is convenient and practical.
