315MHz RF Transmitter and Receiver Module Kit

Description

1. Frequency: 315Mhz
2. Transmitor Input Voltage: 5V

Receiver module parameters

• Product model: MX-RM-5V
• Working voltage: DC5V quiescent current: 4MA
• Receiving frequency: 315MHZ
• Receiver sensitivity: – 105DB
• Size: 30*14*7mm external antenna: 32CM single core wire wound into a spiral

Transmitter head technical parameters

• Product model: MX-FS
• Launch distance: 20 -200 meters (Different voltage, different results) Operating voltage: 3.5-12V Dimensions: 19*19mm
• Ways of working: AM transfer rate: 4KB/S transmit power: 10mW
• Transmitting frequency: 315M
• An external antenna: ordinary 25cm multi-core or single-core line
• Pinout from left → right: (DATA; VCC; GND)

Application environment

Remote control switch, receiver module, motorcycles, auto anti-theft products, home security products, electric doors, shutter doors, windows, remote control socket, remote control LED, remote audio remote control electric doors, garage door remote control, retractable doors remote control, remote volume gate, pan doors, remote controlled door opener, door closer device control system, remote controlled curtains, alarm host, alarm, remote controlled motorcycle electric cars, MP3 remote control.
