3-Pin Green PBT Terminal Block – 5 mm Pitch PCB Mount

Description

3-Pin Screw Terminal

Features & Specifications:

• Pin header                               : Tin plated brass.
• Contacts                                  : Nickel-plated brass.
• Connector                               : PCB Terminal Block
• Termination.                            : Screw
• No. of Contacts                       : 3
• Allowed Wire Size (AWG)        : 24 ~ 16
• Voltage(V).                               : 220V AC
• Operating Current (A)             : 16
• Mounting Type                        : Through Hole
• Pin Spacing (mm)                    : 5
• Material                                   : Metal and plastic
• Length (mm)                            : 15
• Width (mm)                              : 8
• Height (mm)                            : 14

3 Pin 5mm Pitch Plug-in Screw Terminal Block Connector is a type of electrical connector, frequently used to connect wires to the PCB. The connector has a screw in each pin to fasten the wire securely. It has tin-plated brass for pin header and has nickel-plated brass contacts. However, the screw terminal blocks could provide 16A/300V nominal rating for the DC current. The Dielectric strength is more than 2kV.

Other than this, it could provide more than 1000 M ohm Insulation Resistance in 500 VDC. The connector is made using PBT (Polybutylene terephthalate) which is mechanically strong, heat resistant(UL94-V0 or V2) and has good insulation properties.
