1N5817 Schottky Rectifier Diode – Fast-Switching, Low-Forward-Drop (Single Unit)

Description

1N5817 20V ,DO-41 Schottky Barrier Rectifiers

For temporary protection, the 1N5817 is a 1.0A Schottky Barrier Rectifier with guard ring die architecture. For use in polarity protection, free-wheeling, high-frequency inverters, and low-voltage applications. This is a premium Schottky barrier rectifier that regulates voltage and is meant to be used with AC power. It is a quick, effective, and secure way to use DC power at low voltages. In the DC power supply circuit, the Schottky barrier rectifier can be utilized to convert the input AC current into DC current. In circuits involving DC power supplies, the Schottky barrier rectifier can also be employed as a boost converter.
FEATURES:-

• Low forward voltage drop
• Guard ring for overvoltage protection
• High surge current capability
• Best Quality Product

Specification:-

• Maximum repetitive peak reverse voltage : 20V
• Maximum average rectified current : 1.0A
• Peak forward surge current 8.3ms single half sine- wave : 25A
• Maximum reverse current @ VRRM TA = 25°C : 0.5mA
• Package : DO-41
• Feature: Low forward voltage/High current capability/Low leakage current/High surge capability
• Case: Molded plastic use UL 94V-0 recognized Flame retardant epoxy
• Terminals: Axial leads, solderable per MIL-STD-202
• Polarity: Color band denotes cathode
