100-Meter Outdoor Infrared Perimeter Alarm – Dual-Beam Photoelectric Fence Detector

Description

Infrared Detector ABT-100; 2 Beams; Install Distance(Max.) : Outdoor: 100m
Anti-glare up to 50,000 LUX, built-in automatic adjustment strong light filtering system, avoid glare or lighting of car.
Unique optical design: optical glass, beam penetrates the special multi-layer anti-environment (such as rain and snow) and other capabilities
Automatically increase sensitivity when faced with fog or inclement weather.
Detection Mode : 2 Beams Blocked Simultaneous;Optical Source : Infrared Digital Pulse Beam;Response Speed : 50 ~ 700msec

—

Description: Horizontal / vertical optical angle easy to adjust, easy to calibrate.

Specifications: Color: black Material: ABS Size: diameter 17.8cm Working voltage: 12 (V) Alarm current: 65 (mA) Detection angle: 180 ° (± 90 °) Quiescent current: 35 (uA) Working temperature: -25 ℃ ～ 55 ℃ （℃） Detection distance: 20-100 (m)
